PoH:
48V, Each HDBT Outputs: 15.4W, All Outputs: 95W
HDMI:
HDMI, HDCP 2.2, EDID, DVI/D supported with adapter (not included)
ИК:
1x IR Ext — 3.5mm (1/8in) TRS Stereo, Matrix Control10x IR RX — 3.5mm (1/8in) TRS Stereo, 10x IR TX — 3.5mm (1/8in) TS Mono Transmits to Over HDBaseT™
RS-232:
Bidirectional over HDBaseT, Matrix Control, Firmware Updates
Вес:
15.6kg/34.32lbs
Ethernet:
1x 8-pin RJ-45 female, Web UI, IP Control, Bidirectional over HDBaseT™
Wall Box:
4U
HDBaseT™:
HDMI, HDCP 2.2, EDID, ARC, 1-way PoH to Receiver, Bidirectional IR and Ethernet
Входы:
Up to 16x HDMI In: 19-pin type AUp to 16x HDBaseT™ In 8-pin RJ-45 female Up to 16x S/PDIF In Coaxial Digital
Выходы:
Up to 16x HDBaseT Out 8-pin RJ-45 female Up to 16x HDMI Out 19-pin type A (Mirrors HDBaseT™) Up to 16x Optical Out: SFP+Up to 16x S/PDIF Out Coaxial Digital Up to 16x Audio Out 3pin Phoenix Connector
Партномер:
MX-1616-H2XC
Maximum Pixel Clock:
HDMI: 600mHz, HDBaseT™: 297MHz
BTU/БТЕ макс.:
682 BTU/hr
Безопасность:
CE, FCC, RoHS
Наименование:
MX-1616-H2XC
Форматы аудио:
S/PDIF: 2ch PCM, Multichannel: Up to 5.1 DTS and Dolby DigitalHDMI: 2ch PCM, Multichannel: LPCM and Up to DTS-X and Dolby Atmos
Audio Return Channel (ARC):
Returns audio from displays built-in applications via ARC HDMI Input over HDBaseT™
Производитель:
WyreStorm
Задержка «End to End»:
10µs (micro seconds)
Источник питания:
100~240V AC 50/60Hz
Высота с/без ножек:
183.1mm/7.22in, 176mm/6.93in
Глубина с/без ручек:
420.7mm/16.57in, 382.7mm/15.07in
Разрешение видео (макс.):
HDMI1920x1080p @60Hz 12bit (15m/49ft)1920x1200p @60Hz 16bit (7m/23ft)3840x2160p @24Hz 10bit 4:2:0 HDR (3m/10ft)3840x2160p @30Hz 8bit 4:4:4 (7m/23ft)3840x2160p @24Hz 10/12bit HDR 4:2:0 (3m/10ft)4096x2160p @60Hz 8bit 4:2:0 (7m/23ft)4096x2160p @60Hz 8bit 4:4:4 (7m/23ft)Cat61920x1080p @60Hz 12bit (100m/328ft)1920x1200p @60Hz 16bit (100m/328ft)3840x2160p @24Hz 10bit 4:2:0 HDR (70m/230ft)3840x2160p @30Hz 8bit 4:4:4 (70m/230ft)3840x2160p @24Hz 10/12bit HDR 4:2:0 (70m/230ft)4096x2160p @60Hz 8bit 4:2:0 (70m/230ft)4096x2160p @60Hz 8bit 4:4:4 (70m/230ft)1920x1080p @60Hz 12bit (140m/460ft)Cat6a/71920x1080p @60Hz 12bit (100m/328ft)1920x1200p @60Hz 16bit (100m/328ft)3840x2160p @24Hz 10bit 4:2:0 HDR (100m/328ft)3840x2160p @30Hz 8bit 4:4:4 (100m/328ft)3840x2160p @24Hz 10/12bit HDR 4:2:0 (100m/328ft)4096x2160p @60Hz 8bit 4:2:0 (100m/328ft)4096x2160p @60Hz 8bit 4:4:4 (100m/328ft)1920x1080p @60Hz 12bit (140m/460ft)OM31920x1080p @60Hz 12bit (300m/984ft)1920x1200p @60Hz 16bit (300m/984ft)3840x2160p @24Hz 10bit 4:2:0 HDR (300m/984ft)3840x2160p @30Hz 8bit 4:4:4 (300m/984ft)3840x2160p @24Hz 10/12bit HDR 4:2:0 (300m/984ft)4096x2160p @60Hz 8bit 4:2:0 (300m/984ft)4096x2160p @60Hz 8bit 4:4:4 (300m/984ft)
Ширина с/без кронштейнов:
483mm/19.02in, 440mm/17.33in
Поддерживаемые стандарты:
DCI, RGB, HDR, HDR10, Dolby Vision, HLG, BT.2020, BT.2100
Макс. потребляемая мощность:
Default Configuration: 200WNote: Power Consumption increases by +11W for each optional TX-H2X-HDBT card installed.Max of 6 TX-H2X-HDBT cards can be used within a single matrix when using PoH.
Кодирование выходного видео:
HDBaseT™ Class A 5-Play
Скорость кодирования данных:
9.2Bbps
Рабочая температура и влажность:
32°F ~ 113°F (0°C ~ 45°C), 10% ~ 90%, non-condensing
